MS9600SG
Suspended solids (sludge) concentration meter
Typical applications
Feed water plant (sedimentation tank), paper mill (pulp concentration), coal washing plant (sedimentation tank), electric power (mortar sedimentation tank), sewage treatment plant (inlet and outlet, aeration tank, backflow sludge, primary sedimentation tank, secondary sedimentation tank, concentration tank, sludge dewatering)
Instrument features:
● use scattered light and transmitted light detection technology
● optional self-cleaning (air or water flushing) function
● Chinese/English intelligent menu operation
● data recording/uploading function
● a variety of automatic calibration functions
● three sets of relay control switches
● high limit, low limit, hysteresis control
● 4-20ma /RS485 various signal output modes
● password protection can be set to prevent non-staff from misoperation
(1) measuring range:
Concentration: 0 ~ 500mg/L ~ 5000mg/L;
0 ~ 50g/L ~ 100g/L;
Temperature: 0 ~ 50.0℃;
(2) measuring units: mg/L, g/L;
(3) resolution:
Concentration: 0.001mg/L;
0.01 g/L;
Temperature: 0.1℃;
(4) basic error:
Concentration: plus or minus 1% F.S.
Temperature: ±0.3℃;
(5) two-channel current output:
0/4 ~ 20 ma (load resistance < 750 Ω);
(6) communication output: RS485 MODBUS RTU;
(7) three sets of relay control contacts:
5A 250VAC, 5A 30VDC;
(8) power supply (optional) :
85 ~ 265VAC±10%,50±1Hz, power ≤3W;
9 ~ 36VDC, power: ≤3W;
(9) external dimension of the instrument: 144×144×118mm;
(10) instrument installation: disk-mounted, wall-mounted and duct-mounted;
Installation opening size: 138×138mm;
(11) protection grade: IP65;
(12) weight of instrument: 0.8kg;
(13) instrument working environment:
Ambient temperature: -10 ~ 60℃;
Relative humidity: no more than 90%;
